HALF-FRAME 35mm CAMERAS

Half-frame cameras are unique. Sometimes they are known by other names, such as "single-frame" and "split-frame", but whatever you call them, they are probably the most popular of all the subminiature formats.  The half-frame camera was a natural outgrowth of 35mm film which was initially developed for motion picture cameras -- and 35mm still cameras were a natural outgrowth of the half-frame camera -- all of which may surprise you to hear.

W.K.L. Dickson, in an article that he wrote for the SMPTE Journal in 1933, described his central role in the development of Edison's Kinetoscope and Kinetograph.  It gives us a look at how 35mm film and still cameras evolved. Dickson was a researcher for Edison, and was put onto the Motion Picture project in 1887.  By 1888, he was able to make some sort of motion pictures using multiple rows of tiny shots on Carbutt's stiff sensitized celluloid.

Coincidentally, in late 1888, George Eastman's company gave a private demonstration of a new product at the New York Camera Club, which Dickson happened to attend.  He immediately opened discussions with the Eastman company, and was soon dealing directly with George, who supplied them with many samples of short lengths of Eastman's new flexible film. As Dickson worked with the stuff, he came back to Eastman requesting finer grain, greater sensitivity of emulsion, and greater flexibility of the base. He worked very closely with Eastman to refine the product right from the beginning.  Dickson's account gives the impression that the flexible film we know today was developed with a lot of input from the Edison experimenters to meet motion picture needs. He states that he received his first 50-foot rolls of film from Eastman in the spring of 1889, and that:

     "All these samples and experiments were made exclusively for us by Mr. Eastman, who took an ever-increasing interest in what we were doing."

The Edison people had to cut and sprocket the stuff themselves, and it is unclear what the exact width these first 50 foot rolls were. Dickson goes on:

     "At the end of the year 1889, I increased the width of the picture from 1/2 inch to 3/4. The actual width of the film was 1 3/8 inches to allow for perforations now punched on both edges, 4 holes to the phase or picture, which perforations were a shade smaller than those now in use. This standardized film size of 1889 has remained, with only minor variation, unaltered to date."

This was true in 1933, and it's still true today.   It's interesting that he gives the dimensions in inches, not millimeters.  If you measure a piece of 35mm film, you'll see that it's exactly 1 3/8 inches across (only 34.8mm).  So when people ask me what type of film I shoot, I tell the "one and three eigths"!

So in sum, Eastman's flexible base film was developed for motion picture use from its earliest stages, even before it was publicly announced, by a close collaboration between Eastman and the Edison company, and the 35mm format was standardized as early as 1889.  The first still cameras that used 35mm film (approximately 1914) used the same style and format as the movie picture cameras of the time.  The film ran vertically in these still cameras and produced an image of 18mm x 24mm. Years later, when the first horizontally-styled cameras using 35mm film were designed, they were called double frame to separate them from the original format -- which was dubbed single-frame.  These later evolved into the terms -- full-frame and half-frame.  What a history!

While there were many more types of 16mm cameras manufactured over the years, there were many more half-frame cameras sold. This, undoubtedly incomplete, list includes over 120 models. Just about every major camera manufacturer produced a half-frame camera at some point. Some, such as Olympus, produced many different models over the years, many with revolutionary features. In fact, it was the success of the half-frame camera that drove the photographic industry to make all larger-formatted cameras smaller and lighter. The pint-sized, auto-everthing 35mm, APS, and Point & Shoot digital cameras of today owe everything to their half-frame ancestors.  In fact, the APS film format, is many ways, a reincarnation of the half-frame format -- and the APS size and designation still lives on in the digital camera realm!

Most of these half-frame cameras have a format size of 18mm x 24mm, but there are variants such as 17mm x 24mm and 18mm x 23mm. Any camera reasonably close to 18mm x 24mm is listed here. However, full-frame cameras that were capable of also shooting half-frame pictures, such as the Konica Autoreflex, are not listed in the SUBCLUB. In addition, there are a few half-frame cameras that did not use 35mm film. That might seem odd, but they had an 18x24mm format, using a film that was not 35mm wide.

The strong points of the half-frame cameras are: having a relatively large film size, using standard 35mm film, smallish size camera bodies, and getting twice as many pictures on a roll of film as regular format 35mm cameras. Since these cameras have been manufactured up to the present time, there are many half-frame cameras with very modern features, such as autoexposure, motor drives, built-in flash, interchangeable lenses, zoom lenses, and even auto-focusing. And because these cameras use standard 35mm film, they are just as easy to use today as when they were made. And with today's fine grain films, the results can be absolutely astounding, even with significant enlargement of the film.

Please contact us if you have additional information to add to this list.
